5.5 Connecting an optical edge detector
Note the following pin layout
Remove and save the dust protection caps
Route the optical waveguides in accordance with the mounting variant
Further information: "Assembly of the product", Page 40
Adhere to the manufacturer's specifications regarding the
maximum bend radius of the fiber-optic cable
Connect the fiber-optic cable of the light source (reference) to connection X107
Connect the optical waveguide from the projection screen to port X108
Further information: "Device overview", Page 47
Pin layout of X107, X108
1
In
5.6 Wiring switching inputs and outputs
Depending on the peripherals to be connected, the connection work
may need to be carried out by an electrical specialist.
Example: Safety Extra Low Voltage (SELV) exceeded
Further information: "Personnel qualification", Page 29
The product fulfills the requirements of standard IEC 61010-1 only if the
power to the peripheral devices is supplied from a secondary circuit
with current limitation as per IEC 61010-1
3rd Ed.
, Section 9.4 or with
power limitation as per IEC 60950-1
2nd Ed.
, Section 2.5 or from a Class 2
secondary circuit as specified in UL1310.
In place of IEC 61010-1
3rd Ed.
, Section 9.4, the corresponding sections
of standards DIN EN 61010-1, EN 61010-1, UL 61010-1 and CAN/CSA-
C22.2 No. 61010-1can be used, and, in place of IEC 60950-1
2nd Ed.
,
Section 2.5, the corresponding sections of standards DIN EN 60950-1,
EN 60950-1, UL 60950-1, CAN/CSA-C22.2 No. 60950-1 can be applied.
Wire switching inputs and outputs in accordance with the following pin layout
Remove and save the dust protection cap
Route the cables depending on the mounting variant
Further information: "Assembly of the product", Page 40
