Measurement evaluation | Measurement evaluation
11
Selecting the Fitting algorithm
You can adjust the fitting algorithm depending on the measured feature. The
Gaussian fitting algorithm is used by default.
Further information: "Fitting algorithm", Page 278
Drag a feature, e.g., a Circle, from the features list into the
workspace
The Details dialog appears with the Overview tab selected
The fitting algorithm used is shown in the Fitting algorithm
drop-down list
In the Fitting algorithm drop-down list, select the desired
fitting algorithm (e.g., Min. circumscribed)
The feature is displayed according to the selected fitting
algorithm
Figure 66: Circle feature with new fitting algorithm
Tap Close to close the dialog
280
HEIDENHAIN | QUADRA-CHEK 2000 | Operating Instructions | 07/2019
