Measuring | Defining features
10
10.6 Defining features
In some situations, it is necessary to define features. This may be the case, for
example, if a reference used in the technical drawing cannot be established on the
measured object by means of measurement or construction. Here, you can define
the reference on the basis of the coordinate system of the measured object.
4
1
2
3
Figure 62: Define function with Circle geometry
1
Display of the geometry
2
Feature list in the Inspector
3
Input fields for the geometry parameters
4
Geometry parameters
262
HEIDENHAIN | QUADRA-CHEK 2000 | Operating Instructions | 07/2019
