HEIDENHAIN QUADRA-CHEK 2000 User Manual

Installation | Connecting a printer
5
5.7 Connecting a printer
Connecting a USB printer
Comply with the pin layout
Remove and save the dust protection cap
Route the cables based on the mounting variant
Further information: "Assembly of the product", Page 40
Connect USB printer to USB Type-A port (X32). Make sure the USB cable
connector is fully inserted
Further information: "Device overview", Page 47
Pin layout X32
4
3 2 1
1 2 3 4
DC 5 V Data (–) Data (+) GND
Connecting an Ethernet printer
Comply with the pin layout
Remove and save the dust protection cap
Route the cables based on the mounting variant
Further information: "Assembly of the product", Page 40
Connect the Ethernet printer to the Ethernet port X116 using a standard CAT.5
cable. The cable connector must firmly engage in the port
Further information: "Device overview", Page 47
Pin layout of X116
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
D1+
(TX+)
D1-
(TX-)
D2+
(RX+)
D3+ D3– D2–
(RX–)
D4+ D4–
52
HEIDENHAIN | QUADRA-CHEK 2000 | Operating Instructions | 07/2019
