Specifications | Product dimensions and mating dimensions

19.3.3 Product dimensions with Multi-Pos holder

4.5

ISO 14581-M4x8

Md = 2.6 Nm

T25

Md = 15 Nm max.

10°

80°

133

186±1

Figure 99: Product dimensions with Multi-Pos holder

412

HEIDENHAIN | QUADRA-CHEK 2000 | Operating Instructions | 07/2019
