Basic operation | QUADRA-CHEK 2000 – switch-on and switch-off
6
6.4 QUADRA-CHEK 2000 – switch-on and switch-off
6.4.1 Switching on QUADRA-CHEK 2000
Before using the product, you need to perform the commissioning
and setup steps. Depending on the purpose of use, you may have to
configure additional setup parameters.
Further information: "Commissioning", Page 97
Turn the power switch on
The power switch is located on the rear side of the product
The unit powers up. This can take a moment
If automatic user login is active and the last user who logged in was of the
Operator type, the user interface opens with the Measure menu
If automatic user login is not active, the User login menu is displayed
Further information: "User login and logout", Page 61
6.4.2 Activating and deactivating the energy saving mode
If you will not be using the unit for a while, you should activate the energy-saving
mode. This switches the unit to an inactive state without interrupting the power
supply. The screen is switched off in this state.
Activating energy-saving mode
Tap Switch off in the main menu
Tap Energy-saving mode
The screen switches off
Deactivating energy-saving mode
Tap anywhere on the touchscreen
An arrow appears at the bottom of the screen
Drag the arrow up
The screen is switched on and shows the user interface last
displayed
60
HEIDENHAIN | QUADRA-CHEK 2000 | Operating Instructions | 07/2019
