Measuring | Conducting a measurement
To conclude the measuring point acquisition, tap Finish in the
new feature
The measured feature is displayed in the feature list
The measurement result preview is now displayed
The feature can be evaluated
Further information: "Measurement evaluation", Page 275
Figure 59: Measured features in the features view of the workspace and features list of the
Inspector
10
HEIDENHAIN | QUADRA-CHEK 2000 | Operating Instructions | 07/2019
229
