Transport and storage | Items supplied and accessories
3.3.2 Accessories
Software options need to be enabled on the product via a license key.
Before you can use the associated hardware components, you need to
enable the respective software option.
Further information: "Activating the Software options", Page 102
The following accessories are optionally available and can be ordered from
HEIDENHAIN:
Acces-
sories
Name Description ID
For operation
2-D demo part Demonstration part for 2-D
application examples
681047-02
QUADRA-CHEK 2000
AEI1 software option
Enabling of an additional
encoder input
1089227-01
QUADRA-CHEK 2000
AEI1 Trial software
option
Enabling of an additional
encoder input, test version
for a limited time (60 days)
1089227-51
QUADRA-CHEK 2000
OED software option
Automatic measuring point
acquisition via optical edge
detection
1089227-02
QUADRA-CHEK 2000
OED Trial software
option
Automatic point measure-
ment via optical edge
detection, time-limited test
version (60 days)
1089227-52
For installation
2 Vpp adapter connec-
tor
Pin layout conversion from
HEIDENHAIN 1 V
PP
to
Mitutoyo-2 V
PP
1089216-01
Adapter connector
11 µApp
Conversion of the 11 µA
PP
interface from installa-
tion in D-sub connector,
2-row, female, 9-pin to D-
sub connector, 2-row, with
locking screws, male, 15-pin
1089213-01
Adapter connector
1 Vpp
Conversion of the 1 V
PP
interface from installa-
tion in D-sub connector,
2-row, male, 15-pin to D-
sub connector, 2-row, with
locking screws, male, 15-pin
1089214-01
Adapter connector for
TTL
Conversion of the pin layout
from HEIDENHAIN TTL to
RSF TTL and Renishaw TTL
1089210-01
3
HEIDENHAIN | QUADRA-CHEK 2000 | Operating Instructions | 07/2019
35
