Commissioning | OEM area
7
7.4.2 Adding a startup screen
You can define an OEM-specific startup screen, e.g. the company name or logo,
which will be displayed when the product is switched on. An image file with the
following properties needs to be stored on the product for this purpose:
File type: PNG or JPG
Resolution: 96 ppi
Image format: 16:10 (other formats will be scaled proportionally)
Image size: Max. 1280 x 800 px
Adding a startup screen
Tap Settings in the main menu
Tap Service
Open in the sequence
OEM area
Startup screen
Add startup screen
If required, connect a USB mass storage device (FAT32
format) to a USB port of the product
To navigate to the desired file, tap the location where the file
is stored
If you have accidentally tapped the wrong folder, you
can return to the previous folder.
Tap the file name that is displayed above the
list
Navigate to the folder containing the file
Tap the file name
Tap Select
The graphic file is copied to the product and displayed as the
startup screen the next time the product is started
Confirm the successful transfer with OK
Safely removing a USB mass storage device
Tap File management in the main menu
Navigate to the list of storage locations
Tap Safely remove
The message The storage medium can be removed now.
appears
Disconnect the USB mass storage device
When you save the user files, the OEM-specific opening screen is also
saved and can be restored.
Further information: "Back up user files", Page 141
138
HEIDENHAIN | QUADRA-CHEK 2000 | Operating Instructions | 07/2019
