Honda NC700 2012 User Manual

2-9
dummyheaddummyhead
FRAME/BODY PANELS/EXHAUST SYSTEM
SEAT COWL
REMOVAL/INSTALLATION
Remove the following:
– Single seat (page 2-7)
– Grab rail (page 2-8)
Remove the socket bolts [1] and trim clips [2].
Release the seat cowl front side slits [3] and tabs [4] from the side cover tabs [5] and slits [6].
Remove the seat cowl assembly [7] by releasing the its rear side tabs [8] and slits [9] from the rear fender B slits
[10] and tabs [11].
Installation is in the reverse order of removal.
DISASSEMBLY/ASSEMBLY
Remove the center seat cowl (page 2-8).
Remove the seat cowl assembly screws [1] and separate the right and left seat cowls [2].
Assembly is in the reverse order of disassembly.
[2]
[8]
[2]
[3]
[4]
[9]
[6]
[5]
[7]
[10]
[11]
[1]
TORQUE:
Seat cowl assembly screw:
0.9 N·m (0.1 kgf·m, 0.7 lbf·ft)
[1]
[2]

Honda NC700 2012 Specifications

General

Engine Type	670cc liquid-cooled parallel-twin
Bore x Stroke	73.0mm x 80.0mm
Compression Ratio	10.7:1
Front Brake	Single 320mm disc with two-piston caliper
Rear Brake	Single 240mm disc with single-piston caliper
Fuel Capacity	3.7 gallons
Fuel System	PGM-FI
Transmission	6-speed
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock
Front Tire	120/70-17
Rear Tire	160/60-17
Wheelbase	60.6 inches
Curb Weight	472 pounds
