GENERAL INFORMATION
HYDRAULIC BRAKE SPECIFICATIONS
Unit: mm (in)
BATTERY/CHARGING SYSTEM SPECIFICATIONS
ITEM STANDARD SERVICE LIMIT
Front Specified brake fluid DOT 4 –
Brake disc thickness 4.8 – 5.2 (0.19 – 0.20) 4.0 (0.16)
Brake disc warpage – 0.30 (0.012)
Master cylinder I.D. 11.000 – 11.043 (0.4331 – 0.4348) 11.055 (0.4352)
Master piston O.D. 10.957 – 10.984 (0.4314 – 0.4324) 10.945 (0.4309)
Caliper cylinder I.D. (NC700X/S) 27.000 – 27.050 (1.0630 – 1.0650) 27.060 (1.0654)
Caliper piston O.D. (NC700X/S) 26.918 – 26.968 (1.0598 – 1.0617) 26.91 (1.059)
Caliper cylinder I.D.
(NC700XA/XD/SA/SD)
Cylinder A 22.650 – 22.700 (0.8917 – 0.8937) 22.712 (0.8941)
Cylinder B 27.000 – 27.050 (1.0630 – 1.0650) 27.060 (1.0654)
Caliper piston O.D.
(NC700XA/XD/SA/SD)
Piston A 22.585 – 22.618 (0.8892 – 0.8905) 22.56 (0.888)
Piston B 26.918 – 26.968 (1.0598 – 1.0617) 26.91 (1.059)
Rear Specified brake fluid DOT 4 –
Brake disc thickness 4.8 – 5.2 (0.19 – 0.20) 4.0 (0.16)
Brake disc warpage – 0.30 (0.012)
Master cylinder I.D. 14.000 – 14.043 (0.5512 – 0.5529) 14.055 (0.5533)
Master piston O.D. 13.957 – 13.984 (0.5495 – 0.5506) 13.945 (0.5490)
Caliper cylinder I.D. 38.18 – 38.23 (1.503 – 1.505) 38.24 (1.506)
Caliper piston O.D. 38.098 – 38.148 (1.4999 – 1.5019) 38.09 (1.500)
Brake pedal height 85.0 – 87.0 (3.35 – 3.43) –
ITEM SPECIFICATIONS
Battery Type YTZ12S
Capacity 12 V – 11 Ah
Current leakage 1.2 mA maximum
Voltage
(20°C/68°F)
Fully charged 13.0 – 13.2 V
Needs
charging
Below 12.4 V
Charging current Normal 1.1 A/5 – 10 h
Quick 5.5 A/1 h
Alternator Capacity 0.42 kW/5,000 min
-1
(rpm)
Charging coil resistance (20°C/68°F) 0.1 – 0.5
