8-8
dummyheaddummyhead
COOLING SYSTEM
Loosen the water hose band screw [1] and disconnect
the water bypass hose [2].
Remove the bolts [3], stay [4] and thermostat housing
[5].
Remove the O-ring [1].
Remove the bolts [1] and thermostat housing cover [2].
Remove the thermostat [1] from the housing.
[2]
[5][1] [4]
[3]Align
[1]
[2] [1]
[1]
Align
