10-6
dummyheaddummyhead
CYLINDER HEAD/VALVES
Release the fan motor 3P (Gray) connector [1], air
cleaner housing drain hose [2] and spark plug wire [3]
from the radiator.
Lower the radiator and disconnect the crankcase
breather hose [1].
Be careful not to damage the radiator fins.
Remove the cylinder head cover socket bolts [1] and
mounting rubbers [2].
Be careful not to damage the radiator fins.
Remove the cylinder head cover [1] from the cylinder
head.
Be careful not to damage the radiator fins.
Remove the cylinder head cover packing [2] from the
cylinder head cover.
[1] [3]
[2]
[1]
[1]/[2]
[1]
[2]

Honda NC700 2012 Specifications

General

Engine Type	670cc liquid-cooled parallel-twin
Bore x Stroke	73.0mm x 80.0mm
Compression Ratio	10.7:1
Front Brake	Single 320mm disc with two-piston caliper
Rear Brake	Single 240mm disc with single-piston caliper
Fuel Capacity	3.7 gallons
Fuel System	PGM-FI
Transmission	6-speed
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock
Front Tire	120/70-17
Rear Tire	160/60-17
Wheelbase	60.6 inches
Curb Weight	472 pounds
