Honda NC700 2012 User Manual

12-99
dummyheaddummyhead
DUAL CLUTCH TRANSMISSION (DCT) (NC700XD/SD)
Remove the bolts [1] and linear solenoid valve body [2].
Remove the separate plate [1] and dowel pins [2],
Remove the bolts [1] and valve body cover [2].
Remove the wire grommet [3] from the valve body
cover.
Remove the bolt [1], linear solenoid valves [2] and
stopper plate [3] from the valve body.
Remove the stopper plate from the linear solenoid
valves.
[2]
[1]
[1] [2]
[3]
[2]
[1]
[3][1]
[2]

Honda NC700 2012 Specifications

General

Engine Type	670cc liquid-cooled parallel-twin
Bore x Stroke	73.0mm x 80.0mm
Compression Ratio	10.7:1
Front Brake	Single 320mm disc with two-piston caliper
Rear Brake	Single 240mm disc with single-piston caliper
Fuel Capacity	3.7 gallons
Fuel System	PGM-FI
Transmission	6-speed
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock
Front Tire	120/70-17
Rear Tire	160/60-17
Wheelbase	60.6 inches
Curb Weight	472 pounds
