Honda NC700 2012 User Manual

17-7
dummyheaddummyhead
FRONT WHEEL/SUSPENSION/STEERING
NC700SD:
22 N·m (2.2 kgf·m, 16 lbf·ft)
74 N·m (7.5 kgf·m, 55 lbf·ft)
30 N·m (3.1 kgf·m, 22 lbf·ft)
103 N·m (10.5 kgf·m, 76 lbf·ft)
22 N·m (2.2 kgf·m, 16 lbf·ft)
39 N·m (4.0 kgf·m, 29 lbf·ft)
22 N·m (2.2 kgf·m, 16 lbf·ft)

Honda NC700 2012 Specifications

General

Engine Type	670cc liquid-cooled parallel-twin
Bore x Stroke	73.0mm x 80.0mm
Compression Ratio	10.7:1
Front Brake	Single 320mm disc with two-piston caliper
Rear Brake	Single 240mm disc with single-piston caliper
Fuel Capacity	3.7 gallons
Fuel System	PGM-FI
Transmission	6-speed
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock
Front Tire	120/70-17
Rear Tire	160/60-17
Wheelbase	60.6 inches
Curb Weight	472 pounds
