17-23
dummyheaddummyhead
FRONT WHEEL/SUSPENSION/STEERING
Remove the front wheel dust seal [1] from the left wheel
hub.
Assembly is in the reverse order of disassembly.
• Replace the front wheel dust seals and front brake
disc mounting bolts with new ones.
• Apply grease to the front wheel dust seal lips.
• Install the front wheel dust seal until it is flush with
the wheel hub surface.
• Install the front brake disc with the " " marked side
facing out.
[1]
TORQUE:
Front brake disc mounting bolt:
42 N·m (4.3 kgf·m, 31 lbf·ft)
BEARING (6204UU)
BEARING (6204UU)
DUST SEAL
DISTANCE COLLAR
DUST SEAL
BRAKE DISC
42 N·m (4.3 kgf·m, 31 lbf·ft)
PULSER RING
(NC700XA/XD/SA/SD)
