Honda NC700 2012 User Manual

17-37
dummyheaddummyhead
FRONT WHEEL/SUSPENSION/STEERING
Temporarily install the steering stem nut [1] onto the
steering stem [2] to prevent the threads from being
damaged when removing the lower inner race [3] from
the steering stem.
Remove the lower inner race with a chisel or equivalent
tools, being careful not to damage the steering stem.
Remove the steering head bearing dust seal [4].
Apply specified grease to a new steering head bearing
dust seal lips (page 1-23).
Install the steering head bearing dust seal [1] to the
steering stem.
Install a new lower inner race [2] using a hydraulic
press and special tool.
Drive in a new upper outer race [1] using the special
tools.
Drive in a new lower outer race [1] using the special
tools.
[2]
[1]
[3]
[4]
TOOL:
Attachment, 30 mm I.D. [3] 07746-0030300
[1] [3] [2]
TOOLS:
Driver [2] 07749-0010000
Attachment, 42 x 47 mm [3] 07746-0010300
[1]
[3][2]
TOOLS:
Driver [2] 07749-0010000
Attachment, 52 x 55 mm [3] 07746-0010400
[1] [3]
[2]

Honda NC700 2012 Specifications

General

Engine Type	670cc liquid-cooled parallel-twin
Bore x Stroke	73.0mm x 80.0mm
Compression Ratio	10.7:1
Front Brake	Single 320mm disc with two-piston caliper
Rear Brake	Single 240mm disc with single-piston caliper
Fuel Capacity	3.7 gallons
Fuel System	PGM-FI
Transmission	6-speed
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock
Front Tire	120/70-17
Rear Tire	160/60-17
Wheelbase	60.6 inches
Curb Weight	472 pounds
