HYDRAULIC BRAKE
Remove the bolts [1], holder [2] and master cylinder [3].
Installation is in the reverse order of removal.
• Install the master cylinder holder with the "UP" mark
[4] facing up.
• Align the end of the master cylinder with the
handlebar punch mark.
• Tightening the front master cylinder holder bolts,
upper bolt first, then the lower bolt to the specified
torque.
• Replace the sealing washers with new ones.
• Install the brake hose eyelet joint against the master
cylinder stopper.
Fill the reservoir to the upper level and bleed the front
brake system:
– NC700X/S (page 19-9)
– NC700XA/XD/SA/SD (page 19-12)
TORQUE:
Front master cylinder holder bolt:
12 N·m (1.2 kgf·m, 9 lbf·ft)
Brake hose oil bolt:
34 N·m (3.5 kgf·m, 25 lbf·ft)
[2][3]
[1][4]Align

Honda NC700 2012 Specifications

General

Engine Type	670cc liquid-cooled parallel-twin
Bore x Stroke	73.0mm x 80.0mm
Compression Ratio	10.7:1
Front Brake	Single 320mm disc with two-piston caliper
Rear Brake	Single 240mm disc with single-piston caliper
Fuel Capacity	3.7 gallons
Fuel System	PGM-FI
Transmission	6-speed
Front Suspension	41mm telescopic fork
Rear Suspension	Pro-Link single shock
Front Tire	120/70-17
Rear Tire	160/60-17
Wheelbase	60.6 inches
Curb Weight	472 pounds
