Configuring the flow interval
Overview
With the flow interval module, you can view the number of packets and bytes sent/received by a port
and the bandwidth utilization of the port over the specified interval.
Setting the traffic statistics generating interval
1. Select Device > Flow interval from the navigation tree.
2. Click the Interval Configuration tab.
Figure 81 Setting the traffic statistics generating interval
3. Set the traffic statistics generating interval as described in Table 18.
4. Click Apply.
Table 18 Configuration items
Item Descri
tion
Interval for generating traffic statistics
Set the interval for generating port traffic statistics.
Select ports
Select ports from the chassis front panel to apply the interval
to them.
Viewing port traffic statistics
1. Select Device > Flow interval from the navigation tree.
By default, the Port Traffic Statistics tab is displayed.
2. View the number of packets and bytes sent/received by each port and the bandwidth utilization
of each port over the last interval.
