110
Configuring a history entry
1. Select Device > RMON from the navigation tree.
2. Click the History tab.
Figure 88 History tab
3. Click Add.
Figure 89 Adding a history entry
4. Configure a history entry as described in Table 25.
5. Click Apply.
Table 25 Configuration items
Item Descri
Interface Name Select the name of the interface on which the history entry is created.
Buckets Granted
Set the capacity of the history record list corresponding to this history entry, namely,
the maximum number of records that can be saved in the history record list.
If the current number of the entries in the table has reached the maximum number,
the system will delete the earliest entry to save the latest one. The statistics include
total number of received packets on the current interface, total number of broadcast
packets, total number of multicast packets in a sampling period, and so on.
Interval Set the sampling period.
Owner Set the owner of the entry.
