UDP Port
Set UDP port number.
IMPORTANT:
Default port number is 162, which is the SNMP-specified port used for receiving traps
on the NMS. Generally (such as using IMC or MIB Browser as the NMS), you can use the
default port number. To change this parameter to another value, you need to make sure
the configuration is the same with that on the NMS.
Security Model
Select the security model, for which you must set the SNMP version. For the NMS to
receive traps, make sure the SNMP version is the same with that on the NMS.
Security Level
Set the authentication and privacy mode for SNMP traps when the security model is
selected as v3. The available security levels are: no authentication no privacy,
authentication but no privacy, and authentication and privacy.
When the security model is selected as v1 or v2c, the security level is no
authentication no privacy, and cannot be modified.
Displaying SNMP packet statistics
Select Device > SNMP from the navigation tree.
The page for displaying SNMP packet statistics appears.
Figure 120 SNMP Statistics
