HP 1910 User Manual

512
Figure 489 Applying a policy to a port
3. Apply a policy to a port as described in Table 152.
4. Click Apply.
Table 152 Configuration items
Item Descri
p
tion
Please select a policy Select an existing policy in the list.
Direction
Set the direction in which the policy is to be applied. Inbound means to apply the
policy to the incoming packets of the specified ports.
Please select port(s)
Click to select ports to which the QoS policy is to be applied on the chassis front
panel.
Configuring queue scheduling on a port
1. Select QoS > Queue from the navigation tree.
2. Click Setup to enter the queue scheduling configuration page.
Figure 490 Configuring queue scheduling
3. Configure queue scheduling on a port as described in Table 153.
4. Click Apply.

HP 1910 Specifications

General

Model	HP 1910
Category	Switch
Port Type	10/100/1000BASE-T
Layer	Layer 2
PoE Support	No
MAC Address Table Size	8K entries
VLAN Support	Yes
Management	Web-based GUI
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Jumbo Frame Support	Yes
Ports	24
