480
Figure 463 Adding an IPv4 ACL
3. Add an IPv4 ACL as described in Table 132.
4. Click Apply.
Table 132 Configuration items
Item Descri
tion
ACL Number
Set the number of the IPv4 ACL.
Match Order
Set the match order of the ACL.
• Config—Packets are compared against ACL rules in the order that the rules
are configured.
• Auto—Packets are compared against ACL rules in the depth-first match order.
Configuring a rule for a basic IPv4 ACL
1. Select QoS > ACL IPv4 from the navigation tree.
2. Click the Basic Setup tab.
The rule configuration page for a basic IPv4 ACL appears.
