Configure IPv4
address
DHCP Configure how the VLAN interface obtains an IPv4 address.
• DHCP—Specifies the VLAN interface to obtain an IPv4 address by
DHCP.
• BOOTP—Specifies the VLAN interface to obtain an IPv4 address
through BOOTP.
• Manual—Allows you to specify an IPv4 address and a mask length.
BOOTP
Manual
IPv4
address
Specify an IPv4 address and the mask length for the VLAN interface.
Dotted decimal notation is also allowed for the mask length field.
These two fields are configurable if Manual is selected.
Specify the gateway IP address.
By default, the gateway IP address is not specified. Specify the gateway IP
address if the device needs to connect to the Internet.
MaskLen
Gateway
Configure IPv6
link-local address
Auto Configure how the VLAN interface obtains an IPv6 link-local address.
• Auto—Specifies the device to automatically generate an link-local
address based on the link-local address prefix (FE80::/64) and the link
layer address of the interface.
• Manual—Allows you to specify an IPv6 address.
Manual
IPv6
address
Specify an IPv6 link-local address for the VLAN interface.
This field is configurable if Manual is selected. The address prefix must be
FE80::/64.
Finishing configuration wizard
After finishing the management IP address configuration, click Next.
The page displays your configurations. Review the configurations and if you want to modify the settings
click Back to go back to the page. Click Finish to confirm your settings and the system performs the
configurations.
