434
Configuring RADIUS servers
1. Select Authentication > RADIUS from the navigation tree.
The RADIUS server configuration page appears.
Figure 417 RADIUS Server page
2. Configure the RADIUS server parameters as described in Table 118.
3. Click Apply.
Table 118 Configuration items
Item Descri
Server Type
Specify the type of the server to be configured: Authentication Server or
Accounting Sever.
Primary Server IP
Specify the IP address of the primary server.
If no primary server is specified, the field displays 0.0.0.0.
To remove the previously configured primary server, enter 0.0.0.0.
The specified IP address of the primary server cannot be the same as that of the
secondary server.
Primary Server UDP Port
Specify the UDP port of the primary server.
If the IP address of the primary server is not specified or the specified IP address
is to be removed, the port number is 1812 for authentication or 1813 for
accounting.
Primary Server Status
Set the status of the primary server, including:
• Active—The server is correctly operating.
• Blocked—The server is down.
If the IP address of the primary server is not specified or the specified IP address
is to be removed, the status is Blocked.
