HP 1910 User Manual

155
2. Select the Display all VLANs option to display all VLANs or select the Display a subnet of all
configured VLANs option to enter the VLAN IDs to be displayed.
3. Click Select.
Modifying a VLAN
1. Select Network > VLAN from the navigation tree.
2. Click Modify VLAN to enter the page for modifying a VLAN.
Figure 143 Modifying a VLAN
3. Modify the member ports of a VLAN as described in Table 41.
4. Click Apply.
A progress dialog box appears.
5. Click Close on the progress dialog box when the dialog box prompts that the configuration
succeeds.
Table 41 Configuration items
Item Descri
p
tion
Please select a VLAN
to modify
Select the VLAN to be modified.
The VLANs available for selection are existing VLANs selected on the page for
selecting VLANs.
Modify Description
Modify the description string of the selected VLAN.
By default, the description string of a VLAN is its VLAN ID, such as VLAN 0001.
