484

Item Descri

tion

Source

Operator

Select the operators and enter the source port numbers and

destination port numbers as required.

These items are available only when you select 6 TCP or 17

UDP from the Protocol list.

Different operators have different configuration requirements

for the port number fields:

• Not Check—The following port number fields cannot be

configured.

• Range—The following port number fields must be

configured to define a port range.

• Other values—The first port number field must be

configured and the second must not.

Port

Destination

Operator

Port

Precedence

Filter

DSCP

Specify the DSCP value.

IMPORTANT:

If you specify the ToS

precedence or IP precedence

when you specify the DSCP

value, the specified TOS or IP

precedence does not take

effect.

TOS Specify the ToS preference.

Precedence Specify the IP precedence.

Time Range

Select the time range during which the rule takes effect.

Configuring a rule for an Ethernet frame header ACL

1. Select QoS > ACL IPv4 from the navigation tree.

2. Click the Link Layer Setup tab.

The rule configuration page for an Ethernet frame header IPv4 ACL appears.
