tion
WRR
Setup
WRR
Enable or disable the WRR queue scheduling mechanism on selected ports. The
following options are available:
• Enable—Enables WRR on selected ports.
• Not Set—Restores the default queuing algorithm on selected ports.
Queue
Select the queue to be configured.
A queue ID is in the range of 0 to 3.
Group
Specify the group the current queue is to be assigned to.
This list is available after you select a queue ID. The following groups are
available for selection:
• SP—Assigns a queue to the SP group.
• 1—Assigns a queue to WRR group 1.
• 2—Assigns a queue to WRR group 2.
Weight
Set a weight for the current queue.
This list is available when group 1 or group 2 is selected.
Please select port(s)
Click to select ports to be configured with queuing on the chassis front panel.
Configuring GTS on a port
1. Select QoS > GTS from the navigation tree.
2. Click the Setup tab to enter the GTS configuration page.
Figure 491 Configuring GTS on a port
3. Configure GTS on a port as described in Table 154.
4. Click Apply.
Table 154 Configuration items
Item Descri
