brid
In the outbound
direction
Removes the VLAN tag
and sends the frame.
• Removes the tag and sends
the frame if the frame carries
the PVID tag and the port
belongs to the PVID.
• Sends the frame without
removing the tag if its VLAN is
carried on the port but is
different from the PVID.
Sends the frame if its VLAN
is permitted on the port. The
frame is sent with the VLAN
tag removed or intact
depending on your
configuration with the port
hybrid vlan command. This
is true of the PVID.
Recommended VLAN configuration procedures
Assigning an access port to a VLAN
Ste
1. Creating VLANs
Required.
Create one or
multiple VLANs.
2. Configuring the link type of a port
Optional.
Configure the link type of the port as access.
By default, the link type of a port is access.
3. Setting the PVID for a port
Configure the PVID of
the access port.
Required.
An access port has only
one untagged VLAN and
the untagged VLAN is its
PVID. The three operations
produce the same result,
and the latest operation
takes effect.
By default, an access port
is an untagged member of
VLAN 1.
4. Configuring the access ports as untagged
members of a VLAN
a. Selecting VLANs
S
pecify the range of VLANs available for
selection during related operations. Configure
a subset of all existing VLANs. This step is
required before you perform operations on the
Detail, Modify VLAN, and Modify Port tabs.
b. Modifying a VLAN
C
onfigure the access ports as untagged
members of the specified VLAN.
N/A
5. Modifying ports
Configure the
untagged VLAN of the
port.
