Setting the target
Description
Enters the lab values that is indicated on the back of the chart (P/N: 302FZ56990) used for adjustment.
Purpose
Performs data input in order to correct for differences in originals during automatic adjustment.
Method
1. Press the start key.
2. Select the item to be set.
3. Select the item to be set.
4. Enters the value that is indicated on the back of the chart using the cursor +/- keys or numeric keys.
5. Press the start key. The value is set.
6. To return to the screen for selecting an item, press the stop key.
Setting the main and auxiliary scanning directions
1. Measure the distance from the left edge to the black belt (a) of the original at A, B and C.
Measurement procedure
1) Measure the distance from the edge to the black belt (a) of the original at A (50 mm from the leading
edge), B (105 mm from the leading edge) and C (190 mm from the leading edge), respectively.
2) Apply the following formula for the values obtained: ((A + C) / 2 + B) / 2
2. Enter the values solved using the +/- keys in [MAIN ADJ].
3. Press the start key. The value is set.
4. Measure the distance from the leading edge to the black belt (b) of the original at D, E and F.
Measurement procedure
1) Measure the length from the edge to the black belt (b) of the original at D (30 mm from the left edge),
E (148.5 mm from the left edge) and F (267 mm from the left edge), respectively.
2) Apply the following formula for the values obtained: ((D + F) / 2 + E) / 2
5. Enter the values solved using the +/- keys in [SUB LEAD ADJ].
6. Press the start key. The value is set.
7. Measure the length (G) from the leading edge to the bottom of the N475 patch of the original.
8. Enter the measured value using the +/- keys in [SUB TAIL ADJ].
9. Press the start key. The value is set.
10. To return to the screen for selecting an item, press the stop key.
Maintenance
item No.
Description
Display Description
N875 Setting the N875 patch for the original for adjustment
N475 Setting the N475 patch for the original for adjustment
N125 Setting the N125 patch for the original for adjustment
CYAN Setting the cyan patch for the original for adjustment
MAGENTA Setting the magenta patch for the original for adjustment
YELLOW Setting the yellow patch for the original for adjustment
RED Setting the red patch for the original for adjustment
GREEN Setting the green patch for the original for adjustment
BLUE Setting the blue patch for the original for adjustment
ADJUST ORIGINAL Setting the main and auxiliary scanning directions
Display Description Setting range
L Setting the L value 0.0 to 100.0
a Setting the a value -200.0 to 200.0
b Setting the b value -200.0 to 200.0
