2H0/2HZ
1-3-54
U236
Setting the limit for the ejection section of the built-in finisher
Description
If the machine is equipped with an optional built-in finisher, this mode sets whether A5R/B5R/statement size
paper is output to the machine eject tray or not.
Purpose
If the machine is equipped with an optional built-in finisher and if paper jams occur due to curling of paper in
the built-in ejection section when two-sided copying onto A5R/B5R/statement size paper is performed, this
mode is used to change the setting to ON to disable ejection to the machine eject tray.
Setting
1. Press the start key.
2. Select ON or OFF.
Initial setting: OFF
3. Press the start key. The setting is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U243
Checking the operation of the DP motors
Description
Turns the motors and solenoids in the optional DP on.
Purpose
To check the operation of the DP motors or solenoids.
Method
1. Press the start key.
2. Select the item to be operated.
3. Press the start key. The operation starts.
4. To stop operation, press the stop key.
Completion
Press the stop key when operation stops. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
ON Does not eject to the machine eject tray.
OFF Eject to the machine eject tray.
Display Motors and solenoids
DP FEED MOTOR Original feed motor (OFM) is turned on.
DP CONV MOTOR Original conveying motor (OCM) is turned on.
DP REV MOTOR Original switchback motor (OSBM) is turned on.
DP RJ SOL Switchback feedshift solenoid (SBFSSOL) is turned on.
DP RP SOL Switchback pressure solenoid (SBPSOL) is turned on.
To Next Page
