Checking switches for paper conveying
Description
Displays the on-off status of each paper detection switch on the paper path.
Purpose
To check if the switches for paper conveying operate correctly.
Method
1. Press the start key.
2. Turn each switch on and off manually to check the status.
When a switch is detected to be in the ON position, the display for that switch will be highlighted.
*: Optional.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U032
Checking clutch operation
Description
Turns each clutch on.
Purpose
To check the operation of each clutch.
Method
1. Press the start key.
2. Select the clutch to be operated.
3. Press the start key. The clutch turns on for 1 s.
To stop motor driving, press [MOTOR ON] again.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Switches
FEED1 Feed switch 1 (FSW1)
FEED2 Feed switch 2 (FSW2)
FEED3 Feed switch 3 (FSW3)
MP TRAY MP feed switch (MPFSW)
REGIST Registration switch (RSW)
EJECT Eject switch (ESW)
BRANCH Feedshift switch (FSSW)
DUPLEX Duplex paper conveying switch (DUPPCSW)
JOB SEPARATOR Job separator eject switch (JBESW)*
Display Clutches
PF1 Upper paper feed clutch (PFCL-U)
PF2 Lower paper feed clutch (PFCL-L)
PF MP TRAY MP paper feed clutch (MPPFCL)
FEED1 Feed clutch 1 (FCL1)
FEED2 Feed clutch 2 (FCL2)
LIFTBYP MP paper feed clutch (MPPFCL)
FEED MP TRAY MP feed clutch (MPFCL)
REGIST Registration clutch (RCL)
DUPLEX Duplex feed clutch (DUPFCL)
MOTOR ON The main motor (MM) and the paper feed motor (PFM) are
turned ON.
