Checking scanner operation
Description
Simulates the scanner operation under arbitrary conditions.
Purpose
To check scanner operation.
Start
1. Press the start key.
2. Select the item to be operated.
Setting: SCANNER MOTOR
1. Select [SCANNER MOTOR].
2. Select the item.
3. Change the setting using the +/- keys.
Original sizes for each setting in SIZE
4. Press the start key. Scanning starts under the selected conditions.
5. To stop operation, press the stop key.
Method: HOME POSITION
1. Select [HOME POSITION].
2. Press the start key.
The mirror frame of the scanner moves to the home position.
Method: DP READING
1. Select [DP READING].
2. Press the start key.
The mirror frame of the scanner moves to the reading position.
Method: DUST CHECK
1. Select [DUST CHECK].
2. Press the start key. The exposure lamp lights.
3. To turn the exposure lamp off, press the stop key.
Completion
Press the stop key when scanning stops. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
SCANNER MOTOR Scanner operation
HOME POSITION Home position operation
DP READING DP scanning position operation
DUST CHECK Dust adhesion check operation with lamp on
Display Operating conditions Setting range
ZOOM Magnification 25 to 400 %
SIZE Original size See below.
LAMP On and off of the exposure lamp 0 (off) or 1 (on)
Setting Paper size Setting Paper size
5000 A4 5000 A5R
4300 B5 7800 Folio
5100 11" x 8
1/2" 10200 11" x 17"
10000 A3 9000 11" x 15"
8600 B4 8400 8
1/2" x 14"
7100 A4R 6600 8
1/2" x 11"
6100 B5R 5100 5
1/2" x 8 1/2"
