2H0/2HZ
1-3-44
U117
Checking the drum number
Description
Displays the drum number.
Purpose
To check the drum number.
Method
Press the start key. The drum number is displayed.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U118
Displaying the drum history
Description
Displays the past record of machine number and the drum counter.
Purpose
To check the count value of machine number and the drum counter.
Method
Press the start key. Past record of 5 cases is displayed.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U130
Initial setting for the developing unit
Description
Replenishes toner to the developing unit to a certain level from the toner container that has been installed.
Purpose
To operate when installing the machine or replacing the developing unit.
Method
1. Press the start key. The screen for executing is displayed.
2. Press the start key.
Toner installation is started and the output value of the sensor and execution time are displayed.
Completion
Press the stop key after initial setting is complete. The screen for selecting a maintenance item No. is dis-
played.
Maintenance
item No.
Description
Display Description
MACHINE No.1 to 5 Past record of machine number
COUNT 1 to 5 Past record of drum counter
Display Description
TONER SENSOR Output value of the sensor
TIME(SEC) Execution time
