2H0/2HZ-1
1-5-52
(8) Detaching an
d refitting the fuse
r thermostats 1
and 2
Follow the procedure below to replace the fuser thermostats 1 and 2.
Procedure
1.
Remove
the fuser un
it (see p
age 1-
5-41).
2.
Remove four claws and remove the
fuser
unit cover
.
Figure 1-5-94
3.
Remove four tabs.
Figure 1-5-95
Fuser unit cover
Claw
Claw
Claw
Claw
Ta
b
Ta
b
Ta
b
Ta
b
231
