2H0/2HZ
1-3-55
U244
Checking the DP switches
Description
Displays the status of the respective switches in the optional DP.
Purpose
To check if respective switches in the optional DP operate correctly.
Method
1. Press the start key.
2. Turn the respective switches on and off manually to check the status.
When a switch is detected to be in the ON position, the display for that switch will be highlighted.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U245
Checking messages
Description
Displays a list of messages on the touch panel of the operation panel.
Purpose
To check the messages to be displayed.
Method
1. Press the start key.
2. Select the item to be displayed.
3. Displays the message one by one using cursor up/down keys. Switches the language on the touch
panel using the cursor left/right keys.
When a message number is entered with the numeric keys and then the start key is pressed, the mes-
sage corresponding the specified number is displayed.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Switches
DP SET SW Original set switch (OSSW)
DP PSD SW Original size length switch (OSLSW)
DP REV SW Original switchback switch (OSBSW)
CCD TIMING SW DP timing switch (DPTSW)
DP COVER SW DP interlock switch (DPILSW)
DP OPEN SW DP open/close switch (DPOCSW)
