2H0/2HZ
1-3-41
U099
Setting detection sensor threshold value
1. Select an item to be set.
2. Adjust the setting using the +/- or numeric keys.
3. Press the start key. The value is set.
4. To return to the screen for selecting an item, press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U100
Setting the main high voltage
Description
Performs main charging.
Purpose
To check main charging.
Method
1. Press the start key.
2. Select the item to be operated.
3. Press the start key. The selected operation starts.
4. To stop operation, press the stop key.
Completion
Press the stop key when main charger output stops. The screen for selecting a maintenance item No. is dis-
played.
Maintenance
item No.
Description
Display Description Setting
range
Initial
setting
ORIGINAL R Original threshold value (R) 0 to 255 105
ORIGINAL G Original threshold value (G) 0 to 255 105
ORIGINAL B Original threshold value (B) 0 to 255 105
LIGHT SOURCE R Light source threshold value (R) 0 to 255 60
LIGHT SOURCE G Light source threshold value (G) 0 to 255 60
LIGHT SOURCE B Light source threshold value (B) 0 to 255 60
WAIT TIME Time from activation of the original detection switch
(ODSW) to original size judgment
0 to 255 150
A4R AREA Original size detection position display (mm) 220/240 240
Display Description
MC ON Turning the main charger on
LASER ON/OFF Turning the main charger on and the laser scanner unit on and off
To Next Page
General
