2H0/2HZ
1-3-19
U033
Checking solenoid operation
Description
Applies current to each solenoid in order to check its ON status.
Purpose
To check the operation of each solenoid.
Method
1. Press the start key.
2. Select the solenoid to be operated.
3. Press the start key. The solenoid turns on for 1 s.
*Optional.
To stop motor driving, press [MOTOR ON] again.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Solenoids
BRANCH1 Feedshift solenoid (FSSOL)
BRANCH2 Feedshift solenoid (FSSOL)*
MOTOR ON The main motor (MM) and the paper feed motor (PFM) are
turned on.
