2H0/2HZ
1-3-40
U093
Setting: Density in photo mode
1. Select the item to be set.
2. Adjust the setting using the +/- or numeric keys.
Increasing the setting makes the change in density larger, and decreasing it makes the change smaller.
3. Press the start key. The value is set.
4. To return to the screen for selecting an item, press the stop key.
Supplement
While this maintenance item is being executed, copying from an original is available in interrupt copying mode
(which is activated by pressing the system menu key).
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U099
Adjusting original size detection
Description
Checks the operation of the original size detection sensor and sets the sensing threshold value.
Purpose
To adjust the sensitiveness of the sensor and size judgement time if the original size detection sensor mal-
functions frequently due to incident light or the like.
Method
1. Press the start key.
2. Select the item. The screen for executing each item is displayed.
Method to display the data for the sensor
1. Place the original and close the original cover or DP. The detection sensor transmission data is dis-
played.
2. To return to the screen for selecting an item, press the stop key.
Maintenance
item No.
Description
Display Description Setting
range
Initial
setting
PHOTO DARKER Change in density when manual density is set dark 0 to 3 0
PHOTO LIGTER Change in density when manual density is set light 0 to 3 0
Display Description
DATA Displaying detection sensor transmission data
B/W LEVEL Setting detection sensor threshold value
Setting original size judgment time
Display Description
ORIGINAL AREA R Detected original width size (R)
ORIGINAL AREA G Detected original width size (G)
ORIGINAL AREA B Detected original width size (B)
ORIGINAL AREA Detected original width size
SIZE SW L Displays the original detection switch ON/OFF
To Next Page
