2H0/2HZ
1-3-50
U202
Setting the KMAS host monitoring system
Description
Initializes or operates the KMAS host monitoring system.
This is an optional device which is currently supported only by Japanese specification machines, so no setting
is necessary.
U203
Checking DP operation
Description
Simulates the original conveying operation separately in the optional DP.
Purpose
To check the DP operation.
Method
1. Press the start key.
2. Place an original in the DP if running this simulation with paper.
3. Select the item to be operated.
4. When selecting [ADP] or [RADP], to set the magnification using the +/- keys.
5. Press the start key. The operation starts.
6. To stop continuous operation, press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Operation Setting range Initial setting
ADP With paper, single-sided original 100 to 200 (%) 100
RADP With paper, double-sided original 100 to 200 (%) 100
ADP (NON P) Without paper, single-sided original
(continuous operation)
--
RADP (NON P) Without paper, double-sided original
(continuous operation)
--
SPEED Switching between normal reading
(600 dpi) and high-speed reading
0 (Normal)/
1 (high-speed)
0
