2H0/2HZ
1-3-17
U024
HDD formatting
Description
Initializes the HDD.
In addition, the following settings are also initialized by initializing the HDD.
System menu (user login administration, job accounting, address book, one-touch keys and document box
etc.), shortcuts and panel programs
Purpose
To initialize the HDD when replacing the HDD after shipping.
Method
1. Press the start key.
2. Press [EXECUTE] on the touch panel.
3. Press the start key to initialize the hard disk.
4. Turn the main power switch off and on.
U030
Checking motor operation
Description
Drives each motor.
Purpose
To check the operation of each motor.
Method
1. Press the start key.
2. Select the motor to be operated.
3. Press the start key. The operation starts.
4. To stop operation, press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Operation
FEED Paper feed motor operates
MAIN Main motor operates
EJECT(FW) Eject motor rotates forward
EJECT(REV) Eject motor rotates in reverse
DRUM Drum motor operates
