Maintenance parts list
Maintenance part name
Part No.
Alterna-
tive part
Fig.
No.
Ref.
No.
Name used in service manual Name used in parts list
Upper/lower paper feed pulley PULLEY,PAPER FEED 2AR07220 - 5 2
Upper/lower separation pulley PULLEY,SEPARATION 2AR07230 - 5 3
Upper/lower forwarding pulley PULLEY FEED A 2BJ06010 - 5 7
MP paper feed pulley UPPER PULLEY,BYPASS 61706770 - 6 55
MP separation pulley PULLEY,SEPARATION 2AR07230 - 6 2
MP forwarding pulley PULLEY FEED A 2BJ06010 - 6 7
MP feed roller 1 PARTS ROLLER MPF FEED A SP 302H094110 2H094110 7 21
MP feed roller 2 PARTS ROLLER MPF FEED B SP 302H094120 2H094120 7 22
MP feed pulley PULLEY 15 MPF FEED 302H008220 2H008220 7 14
Left registration roller PARTS ROLLER REGIST LEFT SP 302H094140 2H094140 9 29
Right registration roller ROLLER REGIST RIGHT 302H024020 2H024020 9 40
Feed pulley PULLEY 15 DUPLEX 3HY07120 - 4 32
Feed pulley PULLEY 15 DUPLEX 3HY07120 - 9 30
Feed roller 1 PARTS PULLEY MID FEED ASSY SP 302H094430 2H094430 8 A02
Feed roller 2 PARTS ROLLER VERTICAL FEED A SP 302H094090 2H094090 4 22
Feed roller 3 PARTS ROLLER VERTICAL FEED B SP 302H094100 2H094100 4 23
Registration cleaner SPONGE CLEANER REG 302H024240 2H024240 8 19
Laser scanner unit PARTS LK-670 302H093060 2H093060 11 12
Platen CONTACT GLASS 2C912250 - 11 6
Slit glass CONTACT GLASS DP 302H017220 2H017220 11 1
Mirror 1 MIRROR A 302H017150 2H017150 10 46
Mirror 2 and mirror 3 MIRROR B 2AV12160 - 10 2
Reflector REFLECTOR SCANNER 302H017100 2H017100 10 41
Exposure lamp PARTS LAMP SCANNER W SP 302H094130 2H094130 10 42
Original size detection switch SENSOR ORIGINAL 2C927090 - 10 32
Transfer roller unit PARTS TR-670 302H093050 2H093050 9 A02
Separation electrode PLATE STA ELIMINATION 2FT17030 - 9 8
Developing unit PARTS,DV-420,SP 302FT93052 2FT93052 13 1
Drum unit PARTS DK-670 302H093010 2H093010 12 A01
Main charger unit PARTS,MC-420,SP 302FT93083 2FT93083 12 A02
Fuser unit PARTS FK-670(E) 302H093040 2H093040 14 A01
Fuser unit PARTS FK-670(U) 302H093030 2H093030 14 A01
Heat roller PARTS ROLLER HEAT SP 302H094160 2H094160 14 30
Press roller ROLLER PRESS 302H025270 2H025270 14 28
Heat roller separation claw SEPARATOR ASSY B 302FT20160 2FT20160 14 11
Eject roller PARTS ROLLER EXIT INNER SP 302H094370 2H094370 20 35
Switchback roller PARTS ROLLER EXIT FEED SP 302H094360 2H094360 20 34
Eject pulley PULLEY EXIT B 2BL21450 - 20 1
Feed pulley PULLEY EXIT FEED 302H028230 2H028230 20 25
Upper duplex feed roller PARTS DUPLEX A SP 302H094380 2H094380 18 16
Lower duplex feed roller PARTS DUPLEX B SP 302H094390 2H094390 18 17
Duplex feed pulley PULLEY 15 DUPLEX 3HY07120 - 18 18
