2H0/2HZ
-1
1-5-55
1-5-8
PWBs
(1) Detaching and refitting the engine PWB
Follow the procedure below to replace the engine PWB.
Procedure
1.
Remove eleven screws
and remove the rear
cover
.
Figure 1-5-100
2.
Remove three screws.
3.
Remove the claw
.
4.
Remove the connector
.
5.
Remove the high voltage PWB.
Figure 1-5-101
Screws
(eleven)
Rear cover
Screw
Screw
Claw
Screw
High voltage
PWB
Connector
