1-1-2 Parts names
(1) Machine
Figure 1-1-1
1
9
10
11
12
21
23
24 25 26 31
27
28
29
30
2
3
4
5
6
7
8
13
19
15
16
17
18
14
20
22
33
34
35
36
32
1. Original cover (Option)
2. Platen
3. Original size indicator plates
4. Reception indicator
5. Error indicator
6. Left cover 1
7. Left cover 1 Lever
8. Left cover 2
9. Clip holder
10. Operation panel
11. Cassette 1
12. Cassette 2
13. Toner container
14. Toner container stopper
15. Cleaner rod
16. Waste toner box
17. Cleaning brush
18. Knob (A1)
19. Paper feed unit (A2)
20. Paper feed unit cover (A3)
21. USB memory slot
22. Top tray
23. Front cover
24. Paper width adjusting tab
25. Paper length guide
26. Carrying handles
27. Eject stopper
28. Paper width guides
29. Main power switch
30. MP tray
31. Memory card cover
32. USB interface connector
33. Network interface connector
34. Memory card slot
35. Option interface slot (OPT1)
36. Option interface slot (OPT2)
