2H0/2HZ
1-3-16
U021
Initializing counters and mode settings
Description
Initializes all settings, except those pertinent to the type of machine, namely each counter, service call history
and mode setting. Also initializes backup RAM according to region specification selected in maintenance item
U252 Setting the destination.
Refer to *2 of the maintenance mode item list about the item initialized.
Purpose
To return the machine settings to their factory default.
Method
1. Press the start key.
2. Press [EXECUTE] on the touch panel.
3. Press the start key. All data other than that for adjustments due to variations between machines is initial-
ized based on the destination setting.
4. Turn the main power switch off and on.
An error code is displayed in case of an intialization error. Refer to the table of the error codes on P.1-3-15.
When ERROR 09 occurred, turn main power switch off then on, format the hard disk using maintenance
item U024, and execute initialization using maintenance item U021. For other errors occurred, turn main
power switch off then on, and execute initialization using maintenance item U021.
U022
Initializing backup memory
Description
Initializes only the backup data for image processing.
Also, initializes the settings with the system menu in order to restore default settings simultaneously when
[MAIN+ENGINE] is selected.
Reregister the fax settings since the settings are initialized when the fax kit is installed.
Purpose
To be executed as required.
Caution
Run the maintenance item U411 (Adjusting the scanner automatically) after initialization the backup data of
scanner or DP main PWB (see page 1-3-68).
Method
1. Press the start key.
2. Select the item to initialize.
3. When selecting [MAIN+ENGINE], select the destination.
4. Press the start key. All data in the backup RAM is initialized.
5. Turn the main power switch off and on.
An error code is displayed in case of an intialization error. Refer to the table of the error codes on P.1-3-15.
When ERROR 09 occurred, turn main power switch off then on, format the hard disk using maintenance
item U024, and execute initialization using maintenance item U022. For other errors occurred, turn main
power switch off then on, and execute initialization using maintenance item U022.
Maintenance
item No.
Description
Display Description
MAIN+ENGINE Initialize the backup data of main PWB and engine PWB.
SCANNER Initialize the backup data of scanner.
DP Initialize the backup data of DP main PWB.
Display Description
INCH Inch (North America) specifications
EUROPE METRIC Metric (Europe) specifications
ASIA PACIFIC Metric (Asia Pacific) specifications
To Next Page
