2H0/2HZ
1-3-79
U933
Setting the fax backup kit
Description
Initializes optional fax backup kit (memory card) and restore the backup data.
Purpose
To initialize the memory card when call for service (C0700) occurs. Also, to restore data when the hard disk
has been damaged.
Method
1. Press the start key.
2. Select the item.
Method: Restoring the backup data when replacing the HDD
1. Select [FAX IMAGE].
2. Press [EXECUTE].
3. Press the start key. The fax reception data is printed out.
4. Select [JOB ACCOUNTING].
5. Press the start key. The job accounting data is restored.
6. Select [INITIALIZE CF].
7. Press the start key. Memory card is initialized.
8. Turn the main power switch off and on.
Method: When call for service C0700 occurred
1. Select [RECOVERY CF].
2. Press the start key.
3. Turn the main power switch off and on.
4. Select [FAX IMAGE].
5. Press [EXECUTE].
6. Press the start key. Prints the fax images if the images remain in the memory card.
7. Select [INITIALIZE CF].
8. Press the start key. Memory card is initialized.
9. Turn the main power switch off and on.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
INITIALIZE CF Initializes the fax backup kit and backs up the job accounting data in
the hard disk into the fax backup kit.
FAX IMAGE Prints the fax reception data backed up in the fax backup kit.
JOB ACCOUNTING Restores the job accounting data stored in the fax backup kit to the
hard disk.
RECOVERY CF Rewrites the serial number of memory card to put it in active when the
call for service C0700 occurs.
To Next Page
