2H0/2HZ
1-3-56
U246
Setting the finisher
Description
Provides various settings for the built-in finisher, if furnished.
Purpose
Adjusts the side registration cursor stop position if paper registration is poor or stapling is made outside the
specified area.
Setting
1. Press the start key.
2. Select the desired cursor position.
3. Change the setting using the +/- or numeric keys.
4. Press the start key. The value is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U247
Setting the paper feed device
Description
Turns on motor and clutches of optional paper feeder.
Purpose
To check the operation of motors and clutches of paper feeder.
Method
1. Press the start key.
2. Select the item to be operated.
3. Press the start key. The operation starts.
4. To stop operation, press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description Setting
range
Initial
setting
Change in
value per step
FRONT Front side registration cursor stop
position
-4 to +4 0 0.566 mm
REAR Rear side registration cursor stop
position
-4 to +4 0 0.566 mm
END Trailing edge registration cursor stop
position
-4 to +4 0 0.566 mm
Display Motor and clutches
DESK FEED Paper feeder drive motor (PFDM)
CLUTCH FEED Paper feeder conveying clutch (PFCCL)
CLUTCH U Paper feeder paper feed clutch 1 (PFPFCL1)
CLUTCH L Paper feeder paper feed clutch 2 (PFPFCL2)
