2H0/2HZ
1-5-28
(4) Detaching and refitti
ng the ISU (reference)
Follow the procedure below to replace the ISU.
Procedure
1.
Remove two screws and remove the scan-
ner right cover
.
2.
Remove
the platen
.
Figure 1-5-51
3.
Remove six screws and remove the FFC
ground and ISU cover
.
Figure 1-5-52
Screw
Platen
Scanner right cove
r
Screw
FFC ground
ISU cover
Screw
Screw
Screw
Screw
Screw
Screw
207
209
