4.17 MITSUBISHI CNC Machine Operation Panel
4.17.1 Main Panel A , B
(FCU8-KB921 / FCU8-KB922 / FCU8-KB925 , FCU8-KB923 / FCU8-KB924 / FCU8-KB926)
[Outline dimension : FCU8-KB921]
[Outline dimension : FCU8-KB922]
[Outline dimension : FCU8-KB925]
[mm]
260
140
9.5
60
(Space required
for wiring)
[mm]
260
140
9.5
60
(Space required
for wiring)
[mm]
260
140
9.5
60
(Space required
for wiring)
