M800S/M80/E80 Series Connection and Setup Manual
15 Cable
351
IB-1501269-J
15.2.11 J030/J031 Cable
Max. cable length: 15m (the maximum length of the cable when connected to the control unit via other
units)
Application: RS232C I/F cable
(Note 1) Fold the cable shield over the sheath, and wrap copper foil tape over it.
Connect the wound copper foil tape to GND plate of the connector.
(Note 2) Signal names in parentheses "( )" are generally used.
(Note 3) When using the jackscrew M2.6-type 10320-52A0-008 for the shell, do not fasten the screws too tightly
otherwise the connector and the PCB may be damaged.
(Manufacturer recommended tightening torque: 0.20±0.05Nꞏm)
[SIO]
Connector: 10120-3000PE
Case: 10320-52F0-008
Recommended manufacturer: 3M
Wire material: 2464C BIOS-CL3-26
07P
Recommended manufacturer:
Bando Electric Wire
[SIO1][SIO2]
Connector: CDB-25S
Contact: CD-SC-111
Lock nut: HD-LNA
Recommended manufacturer:
Hirose Electric
Cable name SIO1 SIO2
J030 cable
○
J031 cable
○○
○ : Usable channel
SIO
SIO1
SIO2
SIO SIO1
FG
12
2
13
3
14
4
1
17
7
18
8
19
9
11
SD1(TXD1)
RD1(RXD1)
RS1(RTS1)
CS1(CTS1)
ER1(DTR1)
DR1(DSR1)
0V
SD2(TXD2)
RD2(RXD2)
RS2(RTS2)
CS2(CTS2)
ER2(DTR2)
DR2(DSR2)
0V
2
3
4
5
20
6
7
2
3
4
5
20
6
7
SIO2
SD(TXD)
RD(RXD)
RS(RTS)
CS(CTS)
ER(DTR)
DR(DSR)
0V
SD(TXD)
RD(RXD)
RS(RTS)
CS(CTS)
ER(DTR)
DR(DSR)
0V
